Pup joints

Pup joints, an important part of equipment in almost any well.

They are typically easy to handle and use due to their shorter length.

They provide almost same performance as the tubing/casing drill pipe.



All pup joints are made from highest quality API seamless tubing.

Technical specifications
Lengths : 2′, 3′, 4′, 6′, 8′, 10′, 12′, 16′, 20
Diameter Range:  2″ to 20″
Grades: J55/K55, N80, L80, L80-9Cr, L80-13Cr, C90, T95, C95, P110, Q125
Thread type: LC, STC, BTC, EU, NU
Wall thickness: 2.87mm-16.13mm
Weight (PPF): 4 to 19.20 ppf

Customized lengths and Diameters are also available.



Pup joints varying lengths of tubing and casing are used to adjust the production string length as close as possible to the required value.

Pup joints are used to space out the distance between tubing and casing components.

These are also used to adjust the bottom of downhole tools. We provide various thread type and thread size combinations of Pup Joints.
